430–470MHz 3dBi UHF Whip Antenna with SMA Connector
| Parameter | Value |
|---|---|
| Frequency Range | 430–470 MHz (Customizable) |
| Gain (Peak) | 3 dBi |
| Impedance | 50 Ω Nominal |
| VSWR | ≤ 1.5 |
| Return Loss | -10 dB Max |
| Polarization | Vertical / Linear |
| Radiation Pattern | Omnidirectional |
| Efficiency | Not Provided |
| Maximum Input Power | Not Provided |
| Parameter | Value |
|---|---|
| Antenna Type | External Whip Antenna |
| Connector | SMA, Customizable |
| Antenna Material | ABS |
| Color | Black |
| Dimension | Ø14 × 205 mm |
| Cable Type | Not Provided |
| Cable Length | Not Provided |
| Weight | Not Provided |
| Mounting Method | Threaded Connection / Customizable External Mounting Configuration |
| Operating Temperature | Not Provided |
| IP Rating | Not Provided |
Product Content
Short Description
The 430–470MHz 3dBi UHF Whip Antenna is designed for external wireless communication applications, featuring 50Ω impedance, VSWR ≤1.5 and omnidirectional radiation. SMA connector and antenna configuration can be customized for OEM/ODM projects.
Product Overview
The 430–470MHz UHF Whip Antenna is an external omnidirectional antenna designed for wireless communication equipment operating in the UHF frequency range. Its slim 205 mm whip structure provides a practical external antenna solution for professional communication and industrial wireless systems.
The antenna features 3dBi peak gain, 50Ω nominal impedance and VSWR ≤1.5. Its omnidirectional radiation pattern and vertical linear polarization support signal coverage around the antenna when installed in the appropriate orientation.
Designed for integration into wireless telemetry, remote monitoring, IoT/M2M and other UHF communication equipment, the antenna can also be adapted to different project requirements through frequency, connector, cable and mechanical customization.
Key Features
- 430–470 MHz customizable UHF frequency range
- 3 dBi peak gain
- 50 Ω nominal impedance
- VSWR ≤ 1.5
- Omnidirectional radiation pattern
- Vertical linear polarization
- 205 mm slim external whip design
- SMA connector configuration available
- OEM/ODM customization support
Applications
- UHF wireless communication equipment
- Wireless telemetry systems
- Remote monitoring systems
- Industrial wireless terminals
- IoT and M2M communication equipment
- RF communication systems requiring an external antenna
Customization Options
- Frequency range customization
- Connector type customization
- Cable type and cable length customization
- Mechanical structure adjustment
- Mounting configuration customization
- OEM/ODM antenna development
FAQ
Q1: What applications is this 430–470MHz UHF antenna suitable for?
A: It is suitable for UHF wireless communication equipment, telemetry systems, remote monitoring equipment, industrial wireless terminals and compatible IoT/M2M applications operating within the specified frequency range.
Q2: Can the antenna frequency be customized?
A: Yes. The standard reference frequency range is 430–470 MHz, and frequency tuning can be customized according to the customer’s device and RF requirements.
Q3: What connector options are available?
A: An SMA connector configuration is available. Other connector and cable configurations can be customized according to the integration requirements of the customer’s equipment.
Q4: Does Nova Antenna support OEM/ODM service?
A: Yes. Nova Antenna supports OEM/ODM requirements including frequency tuning, connector selection, cable configuration and mechanical design adjustments.
