Product Content

Short Description

The L1+L5 GNSS Positioning Antenna is designed for dual-band satellite navigation and positioning systems, covering 1165–1278 MHz and 1559–1612 MHz with an SMA male connector, RG174 coaxial cable, and compact external housing.

Product Overview

The L1+L5 GNSS Positioning Antenna is an external antenna designed for professional satellite navigation, tracking, telematics, and positioning equipment requiring L1 and L5 frequency coverage.

It operates across 1165–1278 MHz and 1559–1612 MHz with a 50 Ω impedance and VSWR of ≤1.5. The antenna is supplied with RG174 coaxial cable and an SMA male connector with a male center pin for straightforward integration with compatible GNSS receivers and positioning terminals.

The compact 90 × 73 × 29 mm ABS + PC housing includes mounting ears and can be integrated into vehicle tracking terminals, industrial positioning systems, IoT devices, navigation equipment, robotics, and other GNSS-enabled platforms.

Key Features

• Dual-band L1 + L5 GNSS frequency coverage
• 1165–1278 MHz and 1559–1612 MHz frequency ranges
• VSWR ≤1.5
• 50 Ω impedance
• SMA male connector with male center pin
• RG174 coaxial cable
• Compact 90 × 73 × 29 mm housing
• ABS + PC external enclosure
• Integrated mounting ears for equipment installation
• Suitable for professional GNSS positioning equipment
• Cable, connector, frequency, and mechanical customization available
• OEM/ODM antenna development support

Applications

• GNSS positioning systems
• Vehicle tracking equipment
• Fleet management terminals
• Automotive telematics systems
• Navigation equipment
• Industrial positioning systems
• IoT tracking devices
• Robotics and autonomous equipment
• UAV positioning systems
• Asset tracking terminals

Customization Options

• Frequency customization
• Cable length customization
• Connector customization
• Cable assembly customization
• Housing and mechanical design adjustment
• Mounting method customization
• Logo and label customization
• Packaging customization
• OEM/ODM antenna development

FAQ

Q1: What frequency ranges does this L1+L5 GNSS antenna support?

The antenna covers 1165–1278 MHz and 1559–1612 MHz, making it suitable for L5- and L1-related GNSS positioning applications.

Q2: What connector is supplied with the antenna?

The standard configuration shown uses an SMA male connector with a male center pin.

Q3: What type of coaxial cable is used?

The supplied product information identifies RG174 coaxial cable.

Q4: What applications is this antenna suitable for?

It is suitable for GNSS positioning terminals, vehicle tracking systems, telematics equipment, industrial positioning devices, navigation systems, IoT tracking equipment, robotics, and related GNSS applications.

Q5: Can the cable length and connector be customized?

Yes. Cable length, connector type, and cable assembly configuration can be customized according to project requirements.

Q6: Can the antenna frequency be customized?

Yes. Frequency customization can be evaluated according to the target GNSS bands and device requirements.

Q7: Does Nova Antenna support OEM and ODM projects?

Yes. Nova Antenna supports OEM/ODM antenna development, including frequency, cable, connector, mechanical design, mounting, labeling, and packaging customization.
