4G LTE / Cellular On-board SMD Spring Antenna
4G LTE Cellular On Board Smd Spring Antenna is a practical LTE 4G 5G antenna designed for OEM and ODM projects that need stable performance, efficient integration and dependable supply support. It is suitable for customers looking for reliable wireless performance in products where consistent signal quality and compact installation are important. In real applications, 4G LTE Cellular On Board Smd Spring Antenna can be used for iot terminals, smart meters, industrial gateways, routers, kiosks, telematics units and connected devices, especially in projects that require an SMD-friendly structure for efficient board-level assembly; a spring-style radiating element for compact and cost-effective integration. Its structure supports smoother installation, reliable transmission and easier integration into finished devices, helping engineers and product teams shorten development time. Nova Antenna can also support customization based on project requirements, including connector type, cable length, mounting method, frequency band and other integration details. This makes 4G LTE Cellular On Board Smd Spring Antenna a practical choice for customers who need both standard products and flexible RF solution support.
| English Parameter Name | English Parameter Value |
| Product Name | 4G LTE / Cellular On-board SMD Spring Antenna |
| Model | ADCM001 |
| Part Number | M01-X02614M4G1 |
| Dimensions | 26.00×14.78×4.50 mm |
| Weight | 1.1 g |
| Mounting Type | Surface Mount Technology (SMT) |
| Packaging | Reel Packaging |
| Minimum Order Quantity (MOQ) | 500 pcs / reel |
| Operating Frequency | 824-960 MHz / 1710-2690 MHz |
| Max VSWR | 3.69:1 / 2.49:1 |
| Max Efficiency | 77.58% |
| Max Return Loss | -0.20 dB |
| Peak Gain (Typical) | Max 2.24 dBi |
| Max Input Power | 2W CW (Continuous Wave) |
| Polarization | Linear Polarization |
| Input Impedance | 50 Ω |
| Operating Temperature Range | -40° C ~ +80° C |
| Relative Humidity Range | 10% ~ 70% |
